- 6 -

Sicherheitstechnische Kenndaten
der Sicherheitsausgänge

PL nach EN ISO 13849-1

Kategorie nach EN 954-1

SIL CL nach EN IEC 62061

PFH nach EN IEC 62061

SIL nach IEC 61511

PFD nach IEC 61511

t

M

in Jahren

Zeiten

Einschaltverzögerung

Automatischer Start
PNOZ X5 (U

B

: 24 V AC/DC),

PNOZ X5J, PNOZ X5.1
PNOZ X5 (U

B

: 12 V DC)

Manueller Start
PNOZ X5 (U

B

: 24 V AC/DC),

PNOZ X5J, PNOZ X5.1
PNOZ X5 (U

B

: 12 V DC)

Rückfallverzögerung

bei Not-Halt
PNOZ X5 (U

B

: 24 V AC/DC),

PNOZ X5J, PNOZ X5.1
PNOZ X5 (U

B

: 12 V DC)

bei Netzausfall
PNOZ X5 (U

B

: 24 V AC/DC),

PNOZ X5J, PNOZ X5.1
PNOZ X5 (U

B

: 12 V DC)

Wiederbereitschaftszeit bei max.
Schaltfrequenz 1/s

nach Not-Halt
PNOZ X5 (U

B

: 24 V AC/DC),

PNOZ X5J, PNOZ X5.1
PNOZ X5 (U

B

: 12 V DC)

nach Netzausfall
PNOZ X5 (U

B

: 24 V AC/DC),

PNOZ X5J, PNOZ X5.1
PNOZ X5 (U

B

: 12 V DC)

Gleichzeitigkeit Kanal 1 und 2

Überbrückung bei Spannungs-
einbrüchen

PNOZ X5 (U

B

: 24 V AC/DC),

PNOZ X5J, PNOZ X5.1
PNOZ X5 (U

B

: 12 V DC)

Umweltdaten

EMV

Schwingungen nach EN 60068-2-6

Frequenz
Amplitude

Klimabeanspruchung

Luft- und Kriechstrecken nach
EN 60947-1

Verschmutzungsgrad

Bemessungsisloationsspannung

Bemessungsstoßspannungs-
festigkeit

Umgebungstemperatur

Lagertemperatur

Schutzart

Einbauraum (z. B. Schaltschrank)
Gehäuse
Klemmenbereich

Mechanische Daten

Gehäusematerial

Gehäuse
Front

Safety-related characteristics of
the safety outputs

PL in accordance with
EN ISO 13849-1

Category in accordance with
EN 954-1

SIL CL in accordance with
EN IEC 62061

PFH in accordance with
EN IEC 62061

SIL in accordance with IEC 61511

PFD in accordance with IEC 61511

t

M

in years

Times

Switch-on delay

Automatic reset
PNOZ X5 (U

B

: 24 V AC/DC),

PNOZ X5J, PNOZ X5.1
PNOZ X5 (U

B

: 12 V DC)

Manual reset
PNOZ X5 (U

B

: 24 V AC/DC),

PNOZ X5J, PNOZ X5.1
PNOZ X5 (U

B

: 12 V DC)

Delay-on De-Energisation

at E-STOP
PNOZ X5 (U

B

: 24 V AC/DC),

PNOZ X5J, PNOZ X5.1
PNOZ X5 (U

B

: 12 V DC)

with power failure
PNOZ X5 (U

B

: 24 V AC/DC),

PNOZ X5J, PNOZ X5.1
PNOZ X5 (U

B

: 12 V DC)

Recovery time at max. switching
frequency 1/s

after E-STOP
PNOZ X5 (U

B

: 24 V AC/DC),

PNOZ X5J, PNOZ X5.1
PNOZ X5 (U

B

: 12 V DC)

after power failure
PNOZ X5 (U

B

: 24 V AC/DC),

PNOZ X5J, PNOZ X5.1
PNOZ X5 (U

B

: 12 V DC)

Simultaneity channel 1 and 2

Supply interruption before de-
energisation

PNOZ X5 (U

B

: 24 V AC/DC),

PNOZ X5J, PNOZ X5.1
PNOZ X5 (U

B

: 12 V DC)

Environmental data

EMC

Vibration to EN 60068-2-6

Frequency
Amplitude

Climate Suitability

Airgap Creepage in accordance with
EN 60947-1

Pollution degree

Rated insulation voltage

Rated impulse withstand voltage

Ambient temperature

Storage temperature

Protection type

Mounting (eg. panel)
Housing
Terminals

Mechanical data

Housing material

Housing
Front panel

Caractéristiques techniques de
sécurité des sorties de sécurité

PL selon EN ISO 13849-1

Catégorie selon EN 954-1

SIL CL selon EN IEC 62061

PFH selon EN IEC 62061

SIL selon IEC 61511

PFD selon IEC 61511

t

M

en années

Temporisations

Temps de réarmement

Réarmement automatique
PNOZ X5 (U

B

: 24 V AC/DC),

PNOZ X5J, PNOZ X5.1
PNOZ X5 (U

B

: 12 V DC)

Réarmement manuel
PNOZ X5 (U

B

: 24 V AC/DC),

PNOZ X5J, PNOZ X5.1
PNOZ X5 (U

B

: 12 V DC)

Temps de retombée

en cas d'arrêt d'urgence
PNOZ X5 (U

B

: 24 V AC/DC),

PNOZ X5J, PNOZ X5.1
PNOZ X5 (U

B

: 12 V DC)

en cas de coupure d'alimentation
PNOZ X5 (U

B

: 24 V AC/DC),

PNOZ X5J, PNOZ X5.1
PNOZ X5 (U

B

: 12 V DC)

Temps de remise en service en cas de
fréquence de commutation max. 1/s

arrêt d'urgence
PNOZ X5 (U

B

: 24 V AC/DC),

PNOZ X5J, PNOZ X5.1
PNOZ X5 (U

B

: 12 V DC)

après une coupure d'alimentation
PNOZ X5 (U

B

: 24 V AC/DC),

PNOZ X5J, PNOZ X5.1
PNOZ X5 (U

B

: 12 V DC)

Désynchronisme canal 1 et 2

Tenue aux micro-coupures

PNOZ X5 (U

B

: 24 V AC/DC),

PNOZ X5J, PNOZ X5.1
PNOZ X5 (U

B

: 12 V DC)

Données sur l'environnement

CEM

Vibrations selon EN 60068-2-6

Frequence
Amplitude

Conditions climatiques

Cheminement et claquage selon
EN 60947-1

Niveau d'encrassement

Tension assignée d'isolement

Tension assignée de tenue aux
chocs

Température d’utilisation

Température de stockage

Indice de protection

Lieu d'implantation (ex. armoire)
Boîtier
Bornes

Données mécaniques

Matériau du boîtier

Boîtier
Face avant

PL e (Cat. 4)

Cat. 4

SIL CL 3

2,31E-09

SIL 3

2,03E-06

20

typ. 115 ms, max. 180 ms
typ. 124 ms, max. 230 ms

typ. 40 ms, max. 180 ms
typ. 80 ms, max. 230 ms

typ.: 18 ms, max.: 30 ms
typ.: 12 ms, max.: 20 ms

typ.: 110 ms, max.: 160 ms
typ.: 20 ms, max.: 30 ms

50 ms
40 ms

200 ms
50 ms

20 ms
10 ms

EN 60947-5-1,
EN 61000-6-2

10 ... 55 Hz
0,35 mm

EN 60068-2-78

2

250 V

4 kV

-10 ... + 55 °C

-40 ... +85 °C

IP54
IP40
IP20

PPO UL 94 V0
ABS UL 94 V0
