Table 14 — Fan Motor Electrical Data
UNIT
38AH
CONDENSER FAN
Nameplate
V-Ph-Hz
Qty
Hp
(kW)
Total
kW
(No.*) FLA Each
(No.*) LRA Each
044
208/230-3-60
4
1
(0.746)
6.2
(1,2) 5.5 (3,4) 6.6
(1,2) 30.0 (3,4) 31.6
460-3-60
(1,2) 2.8 (3,4) 3.3
(1,2) 30.0 (3,4) 31.6
575-3-60
(1-4) 3.4
(1-4) 30.0
380-3-60
(1-4) 3.9
(1-4) 20.9
230-3-50
(1,2) 5.5 (3,4) 6.8
(1,2) 30.0 (3,4) 31.6
380/415-3-50
(1-4) 3.4
(1-4) 30.0
346-3-50
(1-4) 4.4
(1-4) 20.9
054
208/230-3-60
4
1
(0.746)
6.2
(1,2) 5.5 (3,4) 6.6
(1,2) 30.0 (3,4) 31.6
460-3-60
(1,2) 2.8 (3,4) 3.3
(1,2) 30.0 (3,4) 31.6
575-3-60
(1-4) 3.4
(1-4) 30.0
380-3-60
(1-4) 3.9
(1-4) 20.9
380/415-3-50
(1-4) 3.4
(1-4) 30.0
346-3-50
(1-4) 4.4
(1-4) 20.9
064
208/230-3-60
4
1
(0.746)
6.2
(1,2) 5.5 (3,4) 6.6
(1,2) 30.0 (3,4) 31.6
460-3-60
(1,2) 2.8 (3,4) 3.3
(1,2) 30.0 (3,4) 31.6
575-3-60
(1-4) 3.4
(1-4) 30.0
380-3-60
(1-4) 3.9
(1-4) 20.9
380/415-3-50
(1-4) 3.4
(1-4) 30.0
346-3-50
(1-4) 4.4
(1-4) 20.9
074
208/230-3-60
6
1
(0.746)
9.3
(1,2) 5.5 (3-6) 6.6
(1,2) 30.0 (3-6) 31.6
460-3-60
(1,2) 2.8 (3-6) 3.3
(1,2) 30.0 (3-6) 31.6
575-3-60
(1-6) 3.4
(1-6) 30.0
380-3-60
(1-6) 3.9
(1-6) 20.9
380/415-3-50
(1-6) 3.4
(1-6) 30.0
346-3-50
(1-6) 4.4
(1-6) 20.9
084
208/230-3-60
6
1
(0.746)
9.3
(1,2) 5.5 (3-6) 6.6
(1,2) 30.0 (3-6) 31.6
460-3-60
(1,2) 2.8 (3-6) 3.3
(1,2) 30.0 (3-6) 31.6
575-3-60
(1-6) 3.4
(1-6) 30.0
380-3-60
(1-6) 3.9
(1-6) 20.9
380/415-3-50
(1-6) 3.4
(1-6) 30.0
346-3-50
(1-6) 4.4
(1-6) 20.9
094
208/230-3-60
6
1
(0.746)
9.4
(1,2) 5.5 (3-6) 6.6
(1,2) 30.0 (3-6) 31.6
460-3-60
(1-2) 2.8 (3-6) 3.3
(1,2) 30.0 (3-6) 31.6
575-3-60
(1-6) 3.4
(1-6) 30.0
380-3-60
(1-6) 3.9
(1-6) 20.9
380/415-3-50
(1-6) 3.4
(1-6) 30.0
346-3-50
(1-6) 4.4
(1-6) 20.9
104
208/230-3-60
6
1
(0.746)
9.5
(1,2) 5.5 (3-6) 6.6
(1,2) 30.0 (3-6) 31.6
460-3-60
(1,2) 2.8 (3-6) 3.3
(1,2) 30.0 (3-6) 31.6
575-3-60
(1-6) 3.4
(1-6) 30.0
380-3-60
(1-6) 3.9
(1-6) 20.9
380/415-3-50
(1-6) 3.4
(1-6) 30.0
346-3-50
(1-6) 4.4
(1-6) 20.9
UNIT 38AH
MODULE
124A
124B
134A
208/230-3-60
4
1
(0.746)
6.4
(1,2) 5.5 (3,4) 6.6
(1,2) 30.0 (3,4) 31.6
460-3-60
(1,2) 2.8 (3,4) 3.3
(1,2) 30.0 (3,4) 31.6
575-3-60
(1-4) 3.4
(1-4) 30.0
380-3-60
(1-4) 3.9
(1-4) 20.9
380/415-3-50
(1-4) 3.4
(1-4) 30.0
346-3-50
(1-4) 4.4
(1-4) 20.9
134B
208/230-3-60
6
1
(0.746)
9.2
(1,2) 5.5 (3-6) 6.6
(1,2) 30.0 (3-6) 31.6
460-3-60
(1,2) 2.8 (3-6) 3.3
(1,2) 30.0 (3-6) 31.6
575-3-60
(1-6) 3.4
(1-6) 30.0
380-3-60
(1-6) 3.9
(1-6) 20.9
380/415-3-50
(1-6) 3.4
(1-6) 30.0
346-3-50
(1-6) 4.4
(1-6) 20.9
LEGEND
FLA — Full Load Amps
LRA — Locked Rotor Amps
*Refers to condenser fans by position: See circled numbers on top
views of units in Fig. 1-6.
NOTE: All fans are protected by a single circuit breaker.
