BASE RAIL
BOLTS (6)
CORNER POST
CORNER
POST
Fig. 17 — Units 38AH124 and 134 with Installed Trim
Kit Rails
END COVER
FLANGES
SCREWS B TOP COVER,
VERTICAL
PIECE
VERTICAL
TOP COVER
FLANGE
(HIDDEN)
SCREWS A
END COVER
TOP COVER,
HORIZONTAL
PIECE
CORNER
POST MODULE 124B
OR 134B 24-in. (610-mm)
SERVICE WAY CORNER
POST MODULE 124A
OR 134A
Fig. 18 — Units 38AH124 and 134 with Installed Top
Cover (Unit 38AH134 Shown)
MODULE
124B
OR 134B CORNER
POST (4 PER
MODULE) SCREWS (2)
FOR
MOUNTING
SIDE PANEL CORNER
POST
(4 PER
MODULE) TOP
COVER
FLANGE MODULE
124A
OR 134A
FACTORY-SUPPLIED
SELF-DRILLING
SCREWS (4 PER
CORNER POST)
24-in. (610-mm)
SERVICE WAY
Fig. 19 — Fully Assembled Piping and Trim Kit
(Unit 38AH134 Shown)
