Table 10B — Electrical Data — 50/60 Hz (38AH044-084 Optional Single-Circuit Units)
OPTIONAL SINGLE-CIRCUIT UNIT COMPRESSOR*
38AH
Voltage
Designation
Compressor
A1/A2
Model No.
Nameplate
V-Ph-Hz
Supply Voltage
MCA MOCP ICF
A1 A2
Min Max RLA LRA RLA LRA
044
500
06E4250/250
208/230-3-60 187 254 179.4 225 434.7 67.9 345 67.9 345
600 460-3-60 414 508 91.3 100 218.6 34.6 173 34.6 173
100 575-3-60 518 632 78.4 100 162.4 28.8 120 28.8 120
200 380-3-60 342 418 93.5 125 241.2 34.6 191 34.6 191
800 (PW) 230-3-50 198 254 180.2 225 296.7 67.9 207 67.9 207
900 380/415-3-50 342 440 91.5 100 219.6 34.6 173 34.6 173
300 (PW) 346-3-50 325 367 100.0 125 165.9 33.3 115 33.3 115
054
500
06E4265/250
208/230-3-60 187 254 206.6 250 535.7 89.7 446 67.9 345
600 460-3-60 414 508 102.4 125 268.6 43.6 223 34.6 173
100 575-3-60 518 632 88.0 125 206.4 36.5 164 28.8 120
200 380-3-60 342 418 107.1 150 297.2 45.5 247 34.6 191
900 380/415-3-50 342 440 102.7 125 269.6 43.6 223 34.6 173
300 (PW) 346-3-50 325 367 107.0 150 198.9 44.9 148 33.3 115
064
500
06E8275/265
208/230-3-60 187 254 249.3 350 617.5 106.4 506 89.7 446
600 460-3-60 414 508 115.5 150 307.6 46.8 253 43.6 223
100 575-3-60 518 632 100.6 125 226.1 40.4 176 36.5 164
200 380-3-60 342 418 126.9 175 341.1 52.6 280 45.5 247
900 380/415-3-50 342 440 115.7 150 335.6 46.8 280 43.6 223
300 (PW) 346-3-50 325 367 129.8 175 230.5 53.8 168 44.9 148
074
500
06E8299/275
208/230-3-60 187 254 330.5 450 829.0 147.4 690 106.4 506
600 460-3-60 414 508 148.6 200 408.2 65.4 345 46.8 253
100 575-3-60 518 632 132.2 175 336.8 57.1 276 40.4 176
200 380-3-60 342 418 174.5 250 458.0 78.8 382 52.6 280
900 380/415-3-50 342 440 143.0 200 403.8 65.4 345 46.8 280
300 (PW) 346-3-50 325 367 170.8 250 300.4 79.5 229 53.8 168
084
500
06E8299/299
208/230-3-60 187 254 371.5 500 870.0 147.4 690 147.4 690
600 460-3-60 414 508 167.2 225 426.8 65.4 345 65.4 345
100 575-3-60 518 632 148.9 200 353.5 57.1 276 57.1 276
200 380-3-60 342 418 200.7 250 484.2 78.8 382 78.8 382
900 380/415-3-50 342 440 167.6 225 428.4 65.4 345 65.4 345
300 (PW) 346-3-50 325 367 205.3 250 334.9 79.5 229 79.5 229
LEGEND
FLA — Full Load Amps
ICF — Maximum Instantaneous Current Flow During Starting.
(The point in the starting sequence where the sum of
the LRA for the starting compressors, plus the total RLA
for all running compressors, plus the FLA for all running
fan motors is maximum.)
kcmil — Thousand Circular Mils
LRA — Locked Rotor Amps
Max — Maximum
MCA — Minimum Circuit Amps (used for sizing; complies with
National Electrical Code [NEC] [U.S.A. Standard],
section 430-24).
Min — Minimum
MOCP — Maximum Overcurrent Protection (used for sizing dis-
connect; complies with NEC Article 440, Section 22).
RLA — Rated Load Amps
PW — Part Wind Only
*All compressors are across-the-line start only except 38AH044
230 v, 3-phase, 50 Hz; and all 346 v, 3-phase, 50 Hz.
†Units are suitable for use on electrical systems where voltage sup-
plied to unit terminals is within listed minimum to maximum limits.
NOTES:
1. Maximum allowable phase imbalance: voltage - 2%; amps - 10%.
2. Maximum incoming wire size for terminal block is 500 kcmil.
24
