Propaq Encore Version 1.20 37
English
NIBP
The Propaq Encore noninvasive blood pressure channel (NIBP) indirectly
measures arterial pressures using an inflatable cuff. The Propaq Encore NIBP
channel has been calibrated to agree with a central invasive blood pressure.
Diastolic pressures may be 5 to 10 mmHg lower than the auscultatory equivalent.
Systolic pressures may be lower than the radial invasive equivalent. A summary
of clinical studies is available upon request.
WARNING
When monitoring NIBP on a neonate, set the monitor to Neonatal Mode
unless the circumference of the limb is too large for the cuff. Match the mode
of the Propaq Encore to the style of the cuff. Note that in the Pediatric Mode,
the maximum cuff inflation pressure can exceed 150 mmHg, and three retries
are allowed. (For additional information about the differences between modes,
see NIBP in Appendix B in the
Propaq Encore Reference Guide .)
NIBP Messages
Two new NIBP messages have been added, and the message ADULT HOSE IN
NEONATE MODE has been deleted:
CUFF TOO LARGE FOR PATIENT MODE . This message is displayed when the
monitor detects a cuff too large for the current Patient Mode. First, verify the
patient mode. If the patient mode is correct, check for proper placement and fit of
the cuff to eliminate dead space in the cuff. If the cuff is properly fitted, change the
cuff. If this alert occurs in Neonatal Mode, change the Patient Mode to Pediatric
and check the alarm limits (see Monitor Setup in Chapter 1 and Changing
Individual Limits in Chapter 3 in the Propaq Encore Reference Guide). If the alert
occurs in Pediatric Mode, change the mode to Adult and check the alarm limits.
Note that different pressures and retries are used as stated in the NIBP
Specifications in Appendix B of the Reference Guide.
ARTIFACT PRESENT, MINIMIZE MOTION . This message indicates the
monitor has detected too much movement by the patient to allow accurate
readings. As much as possible, calm the patient or restrain the limb and repeat the
measurement.
