68 Vital Signs Monitor
Sensor Accuracy Grid
* The accuracy specification under motion conditions is + 3. For a definition of motion, contact Nell-
cor Technical Services or your local Nellcor representative.
**The accuracy specification has been determined between saturations of 80% - 99%.
Accuracy Specifications: Accuracy specifications are based on controlled hypoxia studies with
healthy, non-smoking adult volunteers over the specified saturation SpO
2
range. Pulse oximeter
SpO
2
readings were compared to SaO
2
values of drawn blood samples measured by hemoximetry.
All accuracies are expressed as + “X” digits. This variation equals + one standard deviation (+ 1 SD),
which encompasses 68% of the population.
Mechanical Specifications
Dimensions
Height
6.5 inches (16.5cm)
Length 8.6 inches (21.8cm)
Depth 5.0 inches (12.7cm)
Weight
Approximately 6 pounds (2.8Kg)
Sensor Models
SpO
2
Range
70% - 99%
OXIMAX Sensor Models Single Patient Use
MAX-A,* MAX-AL* + 2
MAX-P* + 2
MAX-I* + 2
MAX-R** + 3.5
OxiCliq Sensor Models Single Patient Use
OxiCliq A + 2.5
OxiCliq P + 2.5
Reusable Sensor Models
D-YS (Infant to Adult) + 3
D-YS & D-YSE + 3.5
DS-100A + 3
OXI-A/N (Adult) + 3
OXI-P/I + 3
