Vital Signs Monitor 17
Charging the Battery
The Welch Allyn Vital Signs Monitor may be powered by either AC power or battery power after the
battery has been charged.
UPON INITIALLY RECEIVING THE MONITOR, CHARGE THE BATTERY FOR SIXTEEN (16) HOURS
OR UNTIL THE CHARGING INDICATOR LIGHT NO LONGER FLASHES. The battery is charged by
attaching the AC power transformer to the Monitor, and plugging the AC power transformer into the
AC mains power source.
While charging, the charging indicator will flash a yellow light. When the Monitor is fully charged
the flashing light will be replaced with a solid yellow indicator light.
Power On/Off and System Check Procedure
Each time the Welch Allyn Vital Signs Monitor is turned on, the unit performs an internal self-diag-
nostic check.
To turn the unit on, press the POWER button.
Upon power up, note that all of the LED segments in each display turn on briefly. An audible tone
should also sound. If the internal self-check is successful, the displays will assume their normal
functions and the monitor is ready for operation. If the self-check fails, an error code will be shown
in the displays.
To turn the unit off, press POWER button.
Note that turning the unit off will erase all stored blood pressure, temperature, SpO2 and pulse rate
data.
Setting the Date and Time
1. Initiate the Monitor's internal configuration settings menu by powering up the unit while the
START button is depressed. Hold the START button down until all the LED display segments go
off. The first message displayed is the revision level of the internal software. This will be
displayed in the systolic and diastolic displays.
2. Press the review button four (4) times to advance to the Date Set Screen. The year, month and
day will appear in the systolic, diastolic and heart rate displays respectively.
3. Use the SELECT ALARM button to select the date item to be changed. When selected, the date
item will flash.
4. Use the SET buttons (arrow up or arrow down) to change the selected date item.
5. After making all the desired date changes, press the REVIEW button to save the changes and
advance to the Time Set Screen.
6. When in the Time Set Screen the hour (in 24 hour format) and minutes will appear in the systolic
and diastolic displays respectively. Use the SELECT ALARM and SET buttons to set the time (in
the same manner as described above).
7. When the time is set as desired, press the REVIEW button to save the time and advance to the
next screen.
8. Press the POWER button to turn the Monitor off.
