18 Vital Signs Monitor
Choosing Operating Modes
For all Welch Allyn Vital Signs Monitors which are configured with blood pressure and pulse oxime-
try capability, the operator may choose to make either parameter non-functional. Having both blood
pressure and pulse oximetry operational is the default operating mode. To make either mode non-
functional, the user must enter the Monitor’s configuration mode. This may be accomplished by fol-
lowing these instructions:
• Turn the Monitor off.
• Press both the POWER button and the START button simultaneously. The Monitor will enter
it’s internal configuration mode.
• Press the REVIEW button 9 times. “ON” will appear in both the Systolic and SpO
2
displays.
• Press the SET (arrow up and arrow down) buttons to cycle through the three options
available:
• When the desired functionality is displayed, press the REVIEW button once to save this
selection.
• Turn the Monitor off.
• When the Monitor is turned on, the new functionality setting will be established as the
default level. The Monitor will always revert to this setting on power up.
Blood Pressure Hose & Cuff Connections
Identify and have available each of the following items:
• The Welch Allyn Vital Signs Monitor
• Blood pressure cuff
• Blood pressure hose
Using the illustrations below for reference, perform the following set-up procedures:
1. Inspect the blood pressure hose and note that one end has a connector fitting and the other end
does not. Attach the end without the connector to the pressure hose connector on the monitor
Systolic Display SpO2 Display Monitor Functionality
On On Both blood pressure and pulse oximetry
modes are operational. This is the factory-
default mode.
OFF On Blood pressure mode is disabled. Pulse
oximetry mode is operational.
On OFF Blood pressure mode is operational.
Pulse oximetry mode is disabled.
