Vital Signs Monitor 57
APPENDIX A: Mounting Accessories & Assembly
Instructions
The Welch Allyn Vital Signs Monitor Basket
The mobile stand, IV pole mount and wall mount systems use the same basket.
Attaching the Monitor onto the Basket Assembly
Locate the two "keyhole" slots on the rear of the Monitor and the two circular lugs on the basket
assembly, just above the basket. Insert the lugs into the large openings in the keyhole slots and
slide the Monitor down until it is secured.
Removing the Monitor from the Mobile Stand
Locate the metal tab underneath and toward the back of the Monitor. With one hand in the handle
on top of the Monitor, push on the metal tab and pull up on the Monitor.
Using the Wall Transformer Cord Wrap
On the side of the basket are two hooks which allow the operator to manage the transformer cord.
To use the cord wrap, plug the transformer into the Monitor after installing the Monitor onto the bas-
ket assembly. Wrap the cord around the two hooks in a counter-clockwise motion until there is just
enough cord remaining to allow the transformer plug to rest within the basket.
The Accessory Pack
The accessory pack has the ability to be attached to the mobile stand, the wall mount, the IV pole
mount or on the rear of the Welch Allyn Vital Signs Monitor. The accessory pack is easily exchang-
able from one mounting accessory to another using the quick-release feature. The accessory pack
is designed to hold one box of temperature probe covers, a spare temperature probe or SpO2 sen-
sor. The accessory pack has an integrated cuff clip which can secure any of the cuffs used with the
Monitor.
Attaching the Accessory Pack to the Basket
Locate the two keyhole slots on the plate on the side of the basket assembly, and the two circular
lugs on the back of the accessory pack. Insert the lugs into the large openings in the keyhole slots
and slide the accessory pack UP until it is secured.
Removing the Accessory Pack for the Basket
Locate the metal tab on the bottom of the accessory pack. Push the metal tab away from the bas-
ket and pull down on the accessory pack. The accessory pack will release from the basket.
Attaching and Removing the Accessory Pack from the Monitor
Use the preceeding instructions for attaching and removing the accessory pack from the basket.
