Directions for Use Chapter 5 Maintenance 29
Review Draft Company Confidential Aug 24, 2004
Specifications
Approvals
The Image Capture
System is not working
at all. You need to install .NET
Framework 1.1 The Image Capture System application requires
version 1.1 of the .NET Framework. The Image
Capture System installation program checks the
target computer for the existence of this version
of the framework. If it is found, this step of the
installation process is skipped. If it is not found,
version 1.1 of the .NET Framework is installed. If
you must manually install the .NET Framework
from the installation CD, perform the following
steps:
1. Load the Image Capture System installation
CD into an available CD-ROM drive. If the
installation program initiates, click Cancel
button to shut it down.
2. From the task bar click Start > Run.
3. Using the drive letter of the CD-ROM drive,
assuming it is D:, type "D:\NET Framework
1.1\dotnetfx.exe" then click OK. This will
launch the .NET Framework installation
programand click Yes to continue with the
installation.
4. At the "License Agreement" screen, click I
agree > Install . This step of the procedure
takes a few minutes. When prompted, click
the OK. Installation of the .NET Framework
1.1 is now complete.
Problem Cause Solution
DV Converter: See the DV Converter manual.
Video Colposcope: See the Video Colposcope manual.
PCI or PCMCIA Card: See the card manual.
Cable Lengths: S-Video cable: 20 feet (6 meters)
Composite cable: 12 feet (3.5 meters)
Listed by TUV Rheinland, NA, to the following standards:
UL60601-1, CAN/CSA C22.2 No.601.1, IEC60601-1-1, IEC60601-1-2
