Directions for Use Chapter 4 Performing Spirometry Tests 47
To Print a Test
From the Test Results main screen ( Figure 30 on page 43), follow these steps:
1. Press Print Test.
The following screen appears.
Figure 34. “Print Test” Screen
2. Press the desired softkeys.
Softkey Function Related Information
Efforts Cycles through these print options:
• Best Only
Prints only the best effort of each type
that was saved — best FVC, SVC, FVC-
pre, FVC-post.
• 3 Best
Prints the three best efforts of each
type that was saved.
• All
Prints all efforts.
To change the default option, see “Reviewing
the Spirometry Print Settings” on page 17.
To change the definition of best, see “Select
Best Effort Formula” on page 13.
Curve Cycles through the curve types that are
available to print:
• Vol/Time
• Flow/Vol
• Tidal Vol
• V/T and F/V
• None
To change the default curve type for printed
reports, see
“Reviewing the Spirometry Print
Settings” on page 17.
Print Prints one copy of the test. Press Print again for additional copies.
FVC and SVC efforts print in separate reports.
If “patient education” is enabled in the settings,
one or more patient help sheets automatically
print along with the test. For details, see
“Patient Help Sheets” on page 61.
Back Returns to the Test Results main screen. See Figure 30 on page 43.
Print Test
9:17AM Oct 16 08 Doe, Jane
Efforts
Best Only
Curve
Vol/Time
Print Back
Legend Vol (L)
33
2
4
1
5
Time (s)
Press Print to generate a report
