18

Chapter 2 Reviewing the Spirometry Settings

Welch Allyn CP 200 Spirometry Option

Select FVC Curves

Choose which curve type to print for FVC efforts by default. If desired, you can change the
curve type before you print.

volume/time

flow/volume

tidal volume

V/T & F/V (both volume/time and flow/volume)

V/T & display (when auto print is selected, prints both volume/time and the displayed
curve type if flow/volume or tidal volume; incentive screens do not print.)

no curves

Note: It is not necessary to select a default SVC curve for printing, because SVC curves
are always volume/time.

Select FVC Print
Parameters

Choose which FVC-test parameters to include in printed reports. You may select as many
parameters as you like. If more are selected than fit on a page, the report continues to
another page.

Choices: FVC, FEV1, FEV1%, FEV6, PEF, FEF25-75, FEV0.5, FEV2, FEV3, FEV5, FEV1/FEV6,
FEV0.5%, FEV2%, FEV3%, FEV5%, FEV6%, FEF25, FEF50, FEF75, FEF0.2-1.2, FEF75-85,
FET, FIVC, FIV1, FIV1%, PIF, FIF50, FEF50/FIF50.

Note: It is not necessary to select SVC print parameters, because they all print.

Select Scale

Choose which type of scaling (graph resizing) to use in printed volume/time curves.

Auto scale
Graph is scaled to a small size.

10 mm/s
X axis (time) prints at 10 mm/s. Y axis prints at 10 mm/L.

20 mm/s
X axis (time) prints at 20 mm/s. Y axis prints at 10 mm/L.

Print Lung Age

Yes or no. If yes, the estimated lung age is included in printed reports for patients. For
details, see

“About Lung Age”

on page 71.

Print “Unconfirmed
Report”

Yes or no. If yes, “Unconfirmed Report” is included in printed reports.

Print ”Reviewed By”

Yes or no. If yes, “Reviewed By ______________” is included in printed reports, giving
the clinician a place to sign.

Print “Patient
Cooperation”

Yes or no. If yes, “Patient Cooperation _______________” is included in printed
reports, giving the clinician a place to comment.

Print Quality Grades

Yes or no. If yes, a test-quality grade is included in each printed report. See

“About Test-

Quality Grades”

on page 73.

Print Patient Education Yes or no. If yes, the patient help sheets on asthma and adult smoking prints

automatically with every report. For examples of these sheets, see

“Patient Help Sheets”

on page 61.

Print Physician’s
Comments

Yes or no. If yes, spirometry reports will include an additional blank page (with patient
information at the top) for physician to write comments on.

Auto Print

Yes or no. If yes, a report prints automatically when you press the Test Done softkey.

Setting (continued)

Description (continued)
