18
IQ plus 355 Installation Manual
Level 3 submenus
Primary Units (PRIMAR Parameter)
DECPNT
888888
888880
8.88888
88.8888
888.888
8888.88
88888.8
Decimal point location. Specifies the location of the decimal point or dummy zeroes in the
primary unit display. Value should be consistent with local legal requirements.
DSPDIV
1D
2D
5D
Display divisions. Selects the minimum division size for the primary units displayed weight.
Note: Additional display divisions are available by entering the EDP command 2349171 in
configuration. Selection for 3,4,6,7,8,9,25, and 35 are available when this configuration
command is saved.
UNITS
LB
KG
OZ
TN
T
G
NONE
Specifies primary units for displayed and printed weight. Values are: LB=pound;
KG=kilogram; OZ=ounce; TN=short ton; T=metric ton; G=gram.
NOTE:
Indicators sold outside North America are configured with KG for both primary and
secondary units.
Secondary Units (SECNDR Parameter)
DECPNT
88888.8
888888
888880
8.88888
88.8888
888.888
8888.88
Decimal point location. Determines the location of the decimal point or dummy zeros in
the secondary unit display.
DSPDIV
5D
1D
2D
Display divisions. Selects the value of minimum division size of the displayed weight.
UNITS
KG
OZ
TN
T
G
OFF
NONE
LB
Specifies secondary units for displayed and printed weight. Values are: KG=kilogram;
OZ=ounce; TN=short ton; T=metric ton; G=gram; LB=pound.
MULT
0.453592
Enter other
choices via
keyboard
Multiplier. Specifies the conversion factor by which the primary units are multiplied to
obtain the secondary units. The default is 0.453592, which is the conversion factor for
changing pounds to kilograms. NOTE: This parameter does not display the decimal point
location for some values less than 1; use the MULEXP parameter to shift the decimal
position of the multiplier. See Section 7.6 on page 41 for a list of multipliers.
To toggle between primary and secondary units, press the UNITS key.
MULEXP
decimal
position
Multiplier exponent. Sets the decimal position for multiplier values.
FORMAT Menu
Parameter
Choices
Description
Table 3-3. Format Menu Parameters (Continued)
