EDP Commands 45
Command Description Values
ALG.SOURCE Analog output source GROSS, NET
ALG.OFFSET Zero offset 0%, 20%
ALG.ERRACT Error action FULLSC, HOLD, ZEROSC
ALG.MIN Minimum value tracked 0 – 999999
ALG.MAX Maximum value tracked 0 – 999999
ALG.MINNEG Minimum negative NO, YES
ALG.MAXNEG Maximum negative NO, YES
ALG.TWZERO Zero calibration 0 – 65535
ALG.TWSPAN Span calibration 0 – 65535
ALG.OUTPUT Voltage or current output CURRENT, VOLTAGE
Table 6-8. ALGOUT EDP Commands
Command
(n = setpoint number) Description Values
SP.ENABLE#n Setpoint enable OFF, ON
SP.KIND#n Setpoint kind GROSS, NET, -GROSS, -NET, OFF, DELAY
SP.VALUE#n Setpoint value number
SP.TRIP#n Trip Higher, Lower
SP.PREACT#n Band value number
SP.HYSTER#n Hysteresis number
SP.PUSHPR#n Perform print when setpoint is satisfied OFF, ON
SP.PUSHAC#n Updates accumulator and performs a print
when setpoint is satisfied OFF, ON
SP.PUSHTR#n Perform Tare when setpoint is satisfied OFF, ON
SP.DIGOUT#n Digital outputs NONE, 1 – 4
SP.BATSEQ#n Batch type setpoint OFF, ON
SP.BATCHG#n Batching OFF, AUTO, MANUAL
SP.WAITSS#n Value must be stable OFF, ON
Table 6-9. SETPNTS 1–8 EDP Commands
Command
(p = port number) Description Values
EDP.TRIGER#p EDP port trigger Port 1 – COMAND, DEMAND, PRN, NONE
Port 2 – NONE, PRN, STR-1, STR-2, STR-3, STR-4
EDP.BAUD#p EDP port baud rate 1200, 2400, 4800, 9600, 19200, 38400
EDP.BITS#p EDP port data bits/parity 8NONE, 7EVEN, 7ODD
EDP.SBITS#p EDP port stop bits 1STOP, 2STOP
EDP.TERMIN#p EDP port termination character CR/LF, CR
EDP.EOLDLY#p EDP port end-of-line delay 0 – 255 (0.1-second intervals)
EDP.ECHO#p EDP port echo ON, OFF
EDP.PRNMSG#p Enable print message when a
demand print is performed OFF, ON
EDP.STRUR#p Legal for Trade or industrial stream STRLFT,STRIND
EDP.DEVMOD Specifies the operating mode of
the indicator (see Section 9.4) NONE, LOCAL, REMOTE
Table 6-10. SERIAL EDP Commands
