Page 33

Configuration 29

3.3.2

Format Menu

Figure 3-11. Format Menu

FORMAT Menu

Parameter

Choices

Description

Format submenu

PRIMAR

DECPNT
DSPDIV
UNITS

Primary Units – specifies the capacity, decimal position, display divisions, and units used.
See below for submenu parameter descriptions.

Primary Units submenus

DECPNT

888888
8.88888
88.8888
888.888
8888.88
88888.8

Decimal point location. Specifies the location of the decimal point in the primary unit
display. Value should be consistent with local legal requirements.

DSPDIV

1
2
5
10
20
50

Enter divisions (external) in Primary units. Scale resolution will be determined by the
formula CAP / DIV = Resolution.

UNITS

lb
kg
OZ
TN
T
G

Specifies primary units for displayed and printed weight. Values are: lb = pound;
kg = kilogram; OZ = ounce; TN = short ton; T = metric ton; G = gram

Indicators sold outside North America are configured with kg for both
primary and secondary units.

Format submenu

SECNDR

DECPNT
DSPDIV
UNITS

Secondary Units – specifies the capacity, decimal position, display divisions, units, and
conversion multiplier used. See below for submenu parameter descriptions.

Secondary Units submenus

DECPNT

888888
8.88888
88.8888
888.888
8888.88
88888.8

Decimal point location. Determines the location of the decimal point in the secondary unit
display.

DSPDIV

1
2
5
10
20
50

Enter divisions (external) in Secondary units. Scale resolution will be determined by the
formula CAP / DIV = Resolution.

Table 3-8. Format Menu Parameters

CONFIG

FORMAT

CALIBR

PROGRM

DIG IN

ALGOUT

PASWRD

TEST

MENU

PRIMAR

SECNDR

DSPDIV

UNITS

DECPNT

10d

50d

20d

888888

8888.88

888.888

88.8888

8.88888

88888.8
