Lithium Charge Converter Page 2 of 6
User Interface: (continued)
Input:
- Battery Type Selector:
- 2-position slide switch for M1 mode or LiPo mode
- UP Key
- push button, for detail see operating procedure
- Down Key
- push button, for detail see operating procedure
- Start/Stop Key:
- push button, for detail see operating procedure
Restrictions / Limitations:
• The Lithium Charge Converter requires the user to verify and select the correct
number of cells to match the battery pack about to be charged.
Selecting the correct cell count is the sole responsibility of the user and
neglecting to verify and ensure the proper cell count may result in damage and
or fire.
• Only the following approved NiCd or NiMH chargers should be used:
o
Dynamite - DYN4036 - Prophet Plus™ AC/DC Peak Charger
o
LRP – 41550 - Pulsar Competition **
o
Novak – 4490 – Millennium Pro **
o
Orion Avionics - ORI62200 - Advanced Flight Charger ##
o
Much More - MM-CTXC – CTX Cell Master V1.0
** These chargers will not charge more than 3 cells packs
## Using the NiMH or Nicd modes
• Only use the Lithium Charge Converter with the following approved LiPo
battery packs:
o
Losi LiPo - LOSB9810 - 11.1V 2400mAh 3C LiPo TxPk: Z1, Helios
o
Losi LiPo - LOSB9811 - 11.1V 2400mAh 3C LiPo TxPk: M11, MX-3
o
Losi LiPo - LOSB9820 - 7.4V 2000mAh 2C LiPo Rx Pack
o
Thunder Power - THP21002SPL – 2100mAh 2C 7.4V LiPo
o
Thunder Power - THP20703SX – 2070mAh 3S 11.1V Li-Po
o
Thunder Power - THP20704SX – 2070mAh 4S 14.8V LiPo
o
Thunder Power - THP20705SX – 2070mAh 5S 18.5V LiPo
• Only use the Lithium Charge Converter with the following approved M1
battery packs:
o
A123 Racing - HS-2300-2S1P – 6.6V 2300mAh Hypersonic
o
A123 Racing – HS-4600-2S2P – 6.6V 4600mAh Hypersonic
o
A123 Racing - HS-2300-3S1P – 9.9V 2300mAh Hypersonic
• Power Supply must be capable of providing enough voltage and amperage to
charge the batteries. For example, charging of a 4 or 5 Cell LiPo battery
requires more than 12 volts.
