KTD-S0022-C Page 4 Specifications
KTLX800/pITX User's Guide
❐
Four ports are capable to handle USB 1.1 (OHCI) and USB 2.0 (EHCI)
Onchip Serial Ports (COM)
❐
Two serial ports (RS-232 compatible, status lines not available)
Fast Ethernet (PCI connection): Int l ® 82551ER
❐
Full duplex operation at 10/100 Mbps
E 802.3u
Secure Digital I/O / Multimedia Card (USB connection): SMSC USB2660
❐
Fully compliant with SDIO revision 2.0 and MMC revision 4.2
3 Specifications
3.1 Functional Specifications
Processor: AMD Geode TM LX800
❐
64 kB data and 64 kB instruction L1 cache
❐
128 kB L2 cache
❐
Integrated memory controller run with one DDR200 to DDR400 unbuffered DDR-SDRAM (SO-
DIMM form factor) up to 1GB
❐
Integrated display controller with dual display support (CRT/TFT) and up to 254 MB video
RAM (UMA)
Chipset: AMD Geode TM CS5536
❐
33/66 MHz GeodeLink TM PCI interface
❐
External PCI bus with 32 bit / 33 MHz operation (PCI V2.2 compliant)
❐
One parallel ATA PCI IDE controller
❐
Four USB channels (OHCI/EHCI)
Onchip Video Graphics Array (VGA)
❐
CRT monitor interface (resolution: up to 1920x1440 pixel)
❐
LVDS flatpanel interface supports single clock with 18/24 bit color depth (resolution: max.
1024x768 pixel)
Onchip Universal Serial Bus (USB)
e
❐
Fully compliant with IEEE 802.3 and IEE
