KTD-S0022-C Page 39 Setup Guide
KTLX800/pITX User's Guide
20.3 Main Menu
Feature Description
System Overview Define time and date and show service information
Advanced Settings Configuration of all onboard devices (e.g. CPU, S-ATA, LAN, USB, Display)
PnP/PCI Settings Define PCI/Legacy IRQs
Boot Settings Define the boot sequence and special boot settings
Security Settings Change, set or disable supervisor/user passwords
Load F ts ail-Safe Defaul Set the fail-safe values
Load Optimized Defaults Set the optimized values
Save & Exit p Setu Exit Setup with saving
Exit Without Saving Exit Setup without saving
20.4 System Overview Menu
Feature Option Description
BIOS Version N / A Show the actual BIOS release
Build Date N / A Show the BIOS build date
8Board Information Submenu Show additional service information
System Time HH:MM:SS Set the system time
System Date MM/DD/YYYY Set the system date
20.4.1 Board Information Submenu
Feature Option Description
Board Name N / A Show the KONTRON specific board name
Board Class N / A Show the KONTRON specific board class
Serial Number N / A Show the KONTRON specific serial number
Manufacturing Date N / A Show the KONTRON specific manufacturing date
Hardware Version N / A Show the KONTRON specific hardware version
Boot Counter N / A Display the boot counter
LX800 Chip Revision N / A Show the processor chip revision
CS5536 Chip Revision N / A Show the compagnion chip revision
CPLD Revision N / A Show the CPLD revision (main CPLD)
Base Memory N / A Display amount of base memory
Extended Memory N / A Display amount of extended memory
Total Memory N / A Display amount of total memory
