KTD-S0022-C Page 54 Appendix B: Connector Layout
KTLX800/pITX User's Guide
B.4 Pinout Tables
Pin
CRT
J1604
JILI30 (LVDS)
J1601
Backlight
J1602
1 RED FTX0- N.C.
2 GRN FTX0+ BKLTADJ
3 BLU FTX1- GND
4 N.C. FTX1+ VDD
5 GND FTX2- VDD
6 GND FTX2+ GND
7 GND GND BKLTON
8 GND FTXC-
9 N.C. FTXC+
10 GND FTX3-
11 N.C. FTX3+
12 N.C. RSVD
13 HSYNC RSVD
14 VSYNC GND
15 N.C. RSVD
16 RSVD
17 GND
18 RSVD
19 RSVD
20 RSVD
21 RSVD
22 RSVD
23 RSVD
24 GND
25 SDA
26 DATAENA
27 SCL
28 VCC3/VCC5
29 VCC3/VCC5
30 VCC3/VCC5
Pin
LAN
J1200
USB Standard
J1501
USB Extension
J1500 / J1502
1 TXD+ VCC5 GND
2 TXD- USB0- USBn+
3 RXD+ USB0+ USBn-
4 GND GND VCC5
5 GND VCC5
6 RXD- USB1-
7 GND USB1+
8 GND GND
