KTD-S0022-C Page 16 Graphics Interface
KTLX800/pITX User's Guide
7
he following list shows the video modes supported by the graphics controller with maximum frame buffer
size. When configured for saller frame buffers and/or using a flat panel on the JILI30 interface not all of
the vide
.5 Available Video Modes
T
o modes listed below may be available.
Video Mode Type Characters/Pixels Colors
00h/01h Text 40 x 25 16
02h/03h Text 80 x 25 16
04h/05h Graphic 320 x 200 4
06h Graphic 640 x 200 2
0Dh Graphic 320 x 200 16
0Eh Graphic 640 x 200 16
0Fh Graphic 640 x 350 2
10h Graphic 640 x 350 4
11h Graphic 640 x 480 2
12h Graphic 640 x 480 16
13h Graphic 320 x 200 256
7.6 Ex
Test p am
tended VESA Modes
rogr : SciTech VBETest (VESA BIOS Extensions Compliance Test).
VESA Mode Type Pixels Colors
101h Graphic 640 x 480 256
103h Graphic 800 x 600 256
105h Graphic 1024 x 768 256
107h Graphic 1280 x 1024 256
111h Graphic 640 x 480 64k
112h Graphic 640 x 480 16M (32 bit)
114h Graphic 800 x 600 64k
115h Graphic 800 x 600 16M (32 bit)
117h Graphic 1024 x 768 64k
118h Graphic 1024 x 768 16M (32 bit)
11Ah Graphic 1280 x 1024 64k
11Bh Graphic 1280 x 1024 16M (32 bit)
125h Graphic 1152 x 864 256
127h Graphic 1152 x 864 64k
128h Graphic 1152 x 864 16M (32 bit)
131h Graphic 1600 x 1200 256
133h Graphic 1600 x 1200 64k
134h Graphic 1600 x 1200 16M (32 bit)
