oard with +5V DC instead of the round power jacket (see
er Supply').
Note: The backlight voltage t d throu nector J180 hosen freely.
7.7 Backlight
An external voltage source must be used to supply the backlight with i.e. +12V DC (+5V DC is always avail-
able). The external voltage can be sourced to the backlight connector through the power connector J1801.
This connector can also be used to power the b
chapter 'Pow
hat is source gh con 1 can be c
7.7.1 External Voltage
Parameter Min. Typ. Max. Units
Input voltage +12.0 +30.0 V
Conti input cu nuous rrent 1.0 A
7.7.2 Backlight Voltage Jumper
ge ( Pos. 1-2 = +5V 2-3 = external voltage ). Check the jumper J1603 for the correct backlight volta
