15.3 Power Front Panel Header
The power button and other power signals are available through the pin header J1506 (10 pins).
Header Pin Signal Name Function
RST_BTN+ 1 Reset button (positive)
2 PWR_BTN+ Power button (positive) 1
3 RST_BTN- Reset button (negative)
4 PWR_BTN- Power button (negative)
5 HDD_LED- Harddisk ative) LED (neg
2
9 10
6 RSVD Reserved
HDD_LED+ 7 Harddisk LED (positive)
PWR_LED+ 8 Power itive) LED (pos
PWR_LED- 9 Power LED (negative)
RSVD 10 Reserved
15.3.1 Harddisk and Power LED
ow
Onboard Status LEDs
T D can take the following
s
The foll ing picture illustrates the onboard wiring.
15.4
wo additional LEDs indicate the power and the harddisk status. The power LE
tates.
Power State LED Display
S0 Continuous ON
S3 Blinking
S5 Continuous OFF
