KTD-S0022-C Page
7 Specifications
KTLX800/pITX User's Guide
m)
monitor,
3.3
Mechanical Specifications
Dimensions
➤
Pico-ITX
TM
form factor 100 x 72 mm ±0.2 mm (complete with all connectors 100 x 78 m
➤
Height approx. 26 mm
3.4
Electrical Specifications
Supply Voltage
➤
+5V DC ±5%
Supply Voltage Ripple
➤
Maximum 100mV peak to peak 0 – 20 MHz
Supply Current (DOS prompt)
Power consumption tests were executed during the DOS prompt with 512 MB DDR-SDRAM, DVI
USB keyboard and an USB key as boot device (default BIOS settings).
Full Load
Soft Off S5
[A]
[W]
[A]
[W]
1.09
5.45
0.11
0.55
Supply Current (Windows
®
XP SP3)
The power consumption tests were executed during Windows
®
XP SP3 by using a tool to stress the CPU
(100% load) and extensive 2D graphic. The boards were ran with 512 MB DDR-SDRAM, DVI monitor,
keyboard & mouse and a S-ATA harddisk (default BIOS settings).
USB
Full Load
Idle
Standby S3
[A]
[W]
[A]
[W]
[A]
[W]
1.54
7.7
1.07
5.35
0.14
0.7
