A4

KXAT100 Box E850594

These parts are supplied only if you ordered the KXAT100 ATU option with your kit.

ILLUSTRATION DESCRIPTION

QTY.

ELECRAFT

PART NO.

KXPA100 ATU PCB Assy

1

E850572

KXPA100 Front Panel for ATU

1

E850596

KXAT100 SO239 TMP Cable 4” Envelope E850584

ILLUSTRATION DESCRIPTION

QTY.

ELECRAFT

PART NO.

SO259 – TMP Cable (typical)

SO259 Connector with 4” (10.2 cm)
cable and TMP connector

1 E850600

Screw, Pan Head, Black 4-40,
5/16” (7.9 mm)

4 E700294

Nut, 4-40 with captive star washer

4

E700191

KXAT100 Hardware Envelope E850601

ILLUSTRATION DESCRIPTION

QTY.

ELECRAFT

PART NO.

M-F Standoff, 4-40 3/4" (1.9 cm)

4

E700293

Switch Cap

2

E980250

Lock Washer, Split Ring, #4

4

E700010
