KXPA100 SO239 TMP Cable 4” Envelope E850584
ILLUSTRATION DESCRIPTION
QTY.
ELECRAFT
PART NO.
SO259 – TMP Cable (typical)
SO259 Connector with 4” (10.2 cm)
cable and TMP connector
1 E850600
Screw, Pan Head, Black 4-40,
5/16” (7.9 mm)
4 E700294
Nut, 4-40 with captive star washer
4
E700191
KXPA100 Serial Number Envelope E850602
ILLUSTRATION DESCRIPTION
QTY.
ELECRAFT
PART NO.
Serial Number Label
1
E850602
KXPA100 Bag E850612
These parts are not required or supplied if the KXATU ATU option is ordered with the kit
ILLUSTRATION DESCRIPTION
QTY.
ELECRAFT
PART NO.
Front Panel
1
E100459SS
SO239 Hole Cover
1
E980135
