Nomenclature
• Reference page numbers are indicated in parentheses.
• In the text, camera controls are indicated by their respective icons.
Focusing screen (-^p.127)
Reflex mirror (->p.81)
Seif-timer lamp (^p.79)
Shutter button (^p.14)
Depth-of-field preview
button (-^p.80)
Grip (Battery
chamber) (->p.19)
Lens mount
Lens mount index (->p.21)
Lens lock pin
Lens release button (->p.21)
Grip screw
HP-19)
Tripod socket
Electrical contacts (-^p.7)
Power Drive Booster coupler (cover)
^ Grip
Battery cover
Battery contacts
Electrical contacts
Camera back
lock release
button (->p.25)
Camera back
lever (-^p.25)
Remote control/Data
transfer terminal
(N3 type)
PC terminal (-^p.94)
Power Drive Booster
coupling pin
Eyecup (^p.22)
