92 Installing System Components
Figure 3-16. Removing and Installing an iDRAC6 Express Card
7 Reinstall all expansion cards in the expansion-card riser. See "Installing an
Expansion Card" on page 84.
8 Close the system. See "Closing the System" on page 61.
9 Reconnect the system and peripherals to their power sources, and turn
them on.
1 iDRAC6 Express card 2 plastic standoff tab
3 notch 4 clip
4
2
1
3
