Dell PowerVault DR6000 - Manual (Page 101)

7
Technical Specifications
Processor
Processor type Two Intel Xeon processor E5-2670 product family
Power
AC Power Supply (per power supply)
Wattage 1100 W
Heat dissipation
NOTE: Heat dissipation is calculated using
the power supply wattage rating.
4100 BTU/hr (maximum)
Voltage
NOTE: This system is also designed to be
connected to IT power systems with a
phase to phase voltage not exceeding 230
V.
100–240 V AC, autoranging, 50/60 Hz
Battery 3 V CR2032 Lithium coin cell
Expansion Bus
Bus type PCI Express Generation 3
Expansion slots using riser card:
Riser 1 (Slot 1) One half-height, low-profile x8 link
(Slot 2) One half-height, low-profile x8 link
(Slot 3) One half-height, low-profile x8 link
Riser 2 (Slot 4) One full-height, full-length x16 link
NOTE: To use slots 1 through 4, both the
processors must be installed.
(Slot 5) One full-height, full-length x8 link
Riser 3 (Slot 6) One full-height, full-length x16 link
101
