Operating instructions – Baumer NE131 User Manual
Page 10
www.baumer.com
NE131
10
Operating instructions
Preset counter / Time counter NE131
Mounting
The instrument is designed as built-in counter for in-door use. Please refer to
the following drawings for the cutout measures, the cutout size, as well as
the mounting accessories.
Cutout size Adapter plate Z 118.033
1. Shove instrument with gasket from the front inside the cutout.
2. Shove clamping frame from the back over enclosure and fasten.
60
-0.2
48.7
-0.6
45.45
–0.25
63
–0.
2
75
-0.2
R1
8.3
3
4.3
PLQ
PLQ
