#8 SCREW
E
8: Tap the anchors onto the marked locations up to the
threaded portion with a hammer.
9: Screw in the threaded portion of the anchors with a Phillips
screwdriver.
CEILING
9
11: Feed the #8 screw through the cap and tighten the #8
screw completely into the anchor.
ANCHOR
7: While one person holds the fixture, the other person marks
the standoff location. (Must be within 3ft of electrical
location).
D
NOTE: It is recommended a person to hold the fixture while the
electrician connects the power to the fixture.
CEILING CUTAWAY
FIXTURE
FRAME
STANDOFF 7
G
10: Remove the caps off each standoff.
F
STANDOFF
CAP
10
ANCHOR
11
CAP
12: Carefully, tighten the standoff completely onto the
threaded nipple.
13: Repeat steps 10 through 11 for the remaining standoffs.
ANCHOR
STANDOFF
H
13
8
CEILING
12
