Edge Lighting Vessel 6 - Manual

To reduce the risk of fire, electrical shock, exposure to
excessive UV radiation, or injury to persons:
- Use this fixture indoors only.
- Do not look directly at the lamp while the fixture is on.
- RISK OF FIRE: Use only the type of lamp and maximum
wattage indicated in this instruction manual.
- Never cover the halogen lamp with anything other than a
lamp shield provided by Edge Lighting and never place
flammable material close to the fixture.
- Never turn the fixture on and off by connecting and
disconnecting the halogen lamp.
- Do not touch the fixture head, shade or lamp shield while
the fixture is on. These surfaces may be VERY HOT.
- Do not touch lamp at anytime. Use a soft cloth instead as oil
from skin may damage lamp.
- It is normal for a new halogen lamp to produce minor
smoke when first turned on.
- Do not operate the luminaire with a missing or damaged
shield.
- Turn power off and allow to cool before replacing lamp.
FJ-VESS-_
A
Installation Instructions for Fast Jack Vessel 4 & 6
Install the Lamp
1
904-FJ-VESSEL-01
1718 W. Fullerton Ave
Chicago, IL 60614
Tel: 773-770-1195
Fax: 773-935-5613
www.edgelighting.com
[email protected]
LAMP
SOCKET
CAUTION: To reduce risk of a burn or electrical shock during
lamping, disconnect the power to the fixture.
Use MAX 35 Watt for 4" & 50
for 6" , Type Bi-Pin Halogen Lamp.
Watt
1: Push the lamp pins completely into the socket holes.
2: Push the lamp shield onto the spring clips.
© 2013 Edge Lighting. All Rights Reserved.
SAVE THESE INSTRUCTIONS!
- This product is ETL listed for indoor dry locations and
approved to be used at any height above the finished
floor.
IMPORTANT INFORMATION
IMPORTANT SAFETY INSTRUCTIONS
NOTE: Use a soft cloth and fingers to install the lamp.
B
LAMP SHIELD
SPRING CLIP
1
2
