Edge Lighting Neo Pro Aim MR16 - Manual

SAVE THESE INSTRUCTIONS!
M-NEO-_
FJ- -_ NEO
M2- -_ NEO
- This product is ETL listed for indoor dry locations.
- This product is not restricted to certain height installation.
It is approved to be used at any height above the floor.
- Applicable accessories are Hexcell Louver, Glass Lenses &
MR16 Snout.
A
1: Loosen and remove the shade completely out of the fixture
body.
Neo Pro-Aim Installation Instructions for
Install the Lamp & Lens Accessory
1
904-NEO-02
IMPORTANT INFORMATION
SHADE
1
1718 W. Fullerton Ave
Chicago, IL 60614
Tel: 773-770-1195
Fax: 773-935-5613
www.edgelighting.com
[email protected]
To reduce the risk of fire, electrical shock, exposure to
excessive UV radiation, or injury to persons:
- Use this fixture indoors only.
- Do not look directly at the lamp while the fixture is on.
- RISK OF FIRE: Use only the type of lamp and maximum
wattage indicated in this instruction manual.
- Never cover the halogen lamp with anything other than a
lamp shield provided by Edge Lighting and never place
flammable material close to the fixture.
- Never turn the fixture on and off by connecting and
disconnecting the halogen lamp.
- Do not touch the fixture head, shade or lamp shield while
the fixture is on. These surfaces may be VERY HOT.
- Do not touch lamp at anytime. Use a soft cloth. Oil from skin
may damage lamp.
- It is normal for a new halogen lamp to produce minor
smoke when first turned on.
- Do not operate the luminaire with a missing or damaged
shield.
- Turn power off and allow to cool before replacing lamp.
IMPORTANT SAFETY INSTRUCTIONS
FIXTURE BODY
B
2: Push the lamp pins completely into the socket holes.
CAUTION: To reduce risk of a burn or electrical shock during
lamping, disconnect the power to the fixture.
2
SOCKET
LAMP
Use MAX 50 Watt IR , Type MR16 Front Glass Cover
Halogen Lamp.
© 2009 Edge Lighting. All Rights Reserved.
