Edge Lighting Low Rider Spinner - Manual

M-LOS-_
FJ-LOS-_
M2-LOS-_
A
1: Loosen and remove the knurled nut from the threaded
socket housing.
CAUTION: To reduce risk of a burn or electrical shock during
lamping, disconnect the power to the fixture.
B
3: Align and push the lamp pins completely into the socket
holes.
Low Rider Spinner Installation Instructions for
Install the Lamp & Shade
1
904-SPINNER-04
THREADED SOCKET HOUSING
1
1718 W. Fullerton Ave
Chicago, IL 60614
Tel: 773-770-1195
Fax: 773-935-5613
www.edgelighting.com
[email protected]
To reduce the risk of fire, electrical shock, exposure to
excessive UV radiation, or injury to persons:
– Use this fixture indoors only.
– Do not look directly at the lamp while the fixture is on.
– RISK OF FIRE: Use only the type of lamp and maximum
wattage indicated in this instruction manual.
– Never cover the halogen lamp with anything other than a
lamp shield provided by Edge Lighting and never place
flammable material close to the fixture.
– Never turn the fixture on and off by connecting and
disconnecting the halogen lamp.
– Do not touch the fixture head, shade or lamp shield while
the fixture is on. These surfaces may be VERY HOT.
- Do not touch lamp at anytime. Use a soft cloth. Oil from skin
may damage lamp.
- It is normal for a new halogen lamp to produce minor
smoke when first turned on.
- Do not operate the luminaire with a missing or damaged
shield.
- Turn power off and allow to cool before replacing lamp.
IMPORTANT SAFETY INSTRUCTIONS
KNURLED NUT
THREADED SOCKET HOUSING
KNURLED NUT
SHADE
LAMP
2
3
3
2: Carefully slide the shade onto the threaded socket housing
and secure it by tightening the knurled nut.
© 2009 Edge Lighting. All Rights Reserved.
SAVE THESE INSTRUCTIONS!
- This product is ETL listed for indoor dry locations.
- This product is not restricted to certain height installation.
It is approved to be used at any height above the floor.
- Required shades are Divi,Tapered, or Nico 3.
- Applicable optical accessories Hexcell Louver, or Glass
Lenses.
IMPORTANT INFORMATION
Use MAX 50 Watt IR , Type MR16 Front Glass Cover
Halogen Lamp.
Use MAX 6 Watt LED MR16 Lamp.
