Edge Lighting Bubble Ball - Manual

FJ-BBCL-_
Installation Instructions for Fast Jack Bubble Pendant
904-FJ-BUBBLE-02
1718 W. Fullerton Ave
Chicago, IL 60614
Tel: 773-770-1195
Fax: 773-935-5613
www.edgelighting.com
[email protected]
© 2011 Edge Lighting. All Rights Reserved.
SAVE THESE INSTRUCTIONS!
- This product is ETL listed for indoor dry locations and
approved to be used at any height above the finished
floor.
IMPORTANT INFORMATION
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of fire, electrical shock, exposure to
excessive UV radiation, or injury to persons:
- Use this fixture indoors only.
- Do not look directly at the lamp while the fixture is on.
- RISK OF FIRE: Use only the type of lamp and maximum
wattage indicated in this instruction manual.
- Never cover the halogen lamp with anything other than a
lamp shield provided by Edge Lighting and never place
flammable material close to the fixture.
- Never turn the fixture on and off by connecting and
disconnecting the halogen lamp.
- Do not touch the fixture head, shade or lamp shield while
the fixture is on. These surfaces may be VERY HOT.
- Do not touch lamp at anytime. Use a soft cloth instead as oil
from skin may damage lamp.
- It is normal for a new halogen lamp to produce minor
smoke when first turned on.
- Do not operate the luminaire with a missing or damaged
shield.
- Turn power off and allow to cool before replacing lamp.
Adjust the Fixture Height
A
1: Feed the coaxial cable through the glass shade, and rest
the glass shade over the socket assembly.
COAXIAL CABLE
1
B
H
2: Cut the coaxial cable to the desired height (H) with a sharp
cutter. The overall fixture height is measured from the
bottom of the glass shade to the end of the coaxial cable.
1
SOCKET ASSEMBLY
GLASS SHADE
2
