background image

Model 7i Digital Force / Torque Indicator

User’s Guide


8

N – Newton
kN – Kilonewton
mN – Millinewton

Torque units:
lbFft – Pound-foot
lbFin – Pound-inch
ozFin – Ounce-inch
kgFm – Kilogram-meter
kgFmm – Kilogram-millimeter
gFcm – Gram-centimeter
Nm – Newton-meter
Ncm – Newton-centimeter
Nmm – Newton-millimeter
Note: not all sensor models display all the above units. Refer to the capacity /
resolution table for the respective sensor series for details.

7 Break

Detection

On/Off

The letter “B” appears if the Break Detection function is enabled. Refer to the
Break Detection section for details.

8 Mode

The current measurement mode. Abbreviations are as follows:
RT – Real Time
PC – Peak Compression (for force sensors)
PT – Peak Tension (for force sensors)
PCW – Peak Clockwise (for torque sensors)
PCCW – Peak Counter-clockwise (for torque sensors)
A – Average Mode
ET – External Trigger Mode
See Operating Modes section for details about each of these modes

9

Number of stored
data points

The number of stored data points in memory, up to 5,000. Displayed only if
Memory Storage or Data Capture functions are used.

10

Battery / AC
adapter indicator

Either the AC adapter icon or battery power icon will be shown, depending on
power conditions. Refer to the Power section for details.

11 Automatic

data

output indicator

If Auto Output has been enabled under Serial / USB Settings, this indicator
is displayed. When automatic data output is occurring, the icon becomes
animated. See Communications section for details.

12

High / low limit
indicators

Correspond to the programmed set points. Indicator definitions are as follows:

– the displayed value is greater than the upper load limit
– the displayed value is between the load limits

– the displayed value is less than the lower load limit

13 Set

points

The programmed load limit values. Typically used for pass/fail type testing.
One, two, or no indicators may be present, depending on the configuration
shown in the Set Points menu item.

4.2 Controls

Primary

Label Primary

Function

Secondary

Label Secondary

Function

Powers the indicator on and off.
Press briefly to power on, press and
hold to power off. Active only when
the home screen is displayed.

ENTER

Various uses, as described in the
following sections.

ZERO

Zeroes the primary reading and
peaks.

(UP)

Navigates up through the menu and
sub-menus.

MENU

Enters the main menu.

ESCAPE

Reverts one step backwards through
the menu hierarchy.
