Model 7i Digital Force / Torque Indicator

User’s Guide


12

To enable Break Detection and configure the automatic functions, select Break Detection from the main
menu. The display appears as follows:


Select “+ More” for additional options:


Any combination of the above functions may be selected.


If tones are enabled, a tone will sound when the output, storage, and zero functions have occurred.

7.2 Break Settings
Select Break Settings from the main menu to configure the settings. The display appears as follows:







Function Description

Enabled-End Test

Arms the break detection function. When enabled, the letter “B” appears on the
home screen, between the Mode and Unit indicators. Refer to the Home Screen
and Controls
section for details. Applies to modes in which a

Break Detect Stop

Condition is specified.

Enabled-Abort

Same as above, except applies to situations in which a premature break occurs
before the specified

Stop Condition is reached.

Break Settings

Refer to the following sub-sections for details.

Auto Output
Auto Storage

Automatically stores the peak reading to memory.

Auto Zero

Automatically zeroes the display following data transmission and/or storage.

BREAK DETECTION 2


* Auto Storage
* Auto Zero
Auto Zero Delay

3 sec.

BREAK DETECTION

SETTINGS


Threshold: 5 %
% Drop: 50 %

BREAK DETECTION

*

Disabled

Enabled-End Test

Enabled-Abort
+ Break Settings
+ Auto Output
+ More
