Select “+ More” for additional options:
9.6.3 Stop Condition
Data capture is automatically terminated when the Stop Condition has been reached. Several conditions
are available, as shown below:
When data capture has stopped, the data may be automatically transmitted in bulk to a PC program such
as MESUR
TM gauge (see the following sub-section for details). Data may also be transmitted manually
through the Memory section.
Note 1: If the Stop Condition does not occur, data capture stops automatically when the memory
is full.
Function Data capture is initiated when:
Momentary Hi Lo
An external trigger occurs.
See External Trigger sub-section for details for each of these functions.
Momentary Lo Hi
Maintained High
Maintained Low
Start Load
The desired trigger load is reached. Toggle between measurement directions
by pressing the DIRECTION key.
DATA Key The DATA key is manually pressed.
Function Data capture terminates when:
Samples The desired number of samples (data points) has been captured.
Stop Load The desired load has been reached.
Memory Full 5,000 data points have been captured.
DATA Key The DATA key is manually pressed.
START CONDITION 2
Start Load
3.500 lbFin
* DATA Key
STOP CONDITION
*
Samples: 10
Stop Load
2.500 lbFin
Memory Full
DATA Key
START CONDITION
Momentary Hi
Lo
Momentary Lo Hi
* Maintained High
Maintained Low
+ More
