Model 7i Digital Force / Torque Indicator User’s Guide
35
Causes:
1. The calibration weight does not match the set value.
2. If using a PTA configurable adapter, ensure that the output signal leads (SG+ and SG-) have
been installed into the appropriate terminal blocks. Some sensor manufacturers consider
SG+ to be a compression value, while others consider it to be a tension value. If the indicator
is expecting a compression load but it is receiving a tension signal, calibration cannot
continue. Verify that the tension/compression indicator on the home screen properly
corresponds to the load direction, and switch the signal leads, if required.
The entered calibration point is too close to the previous point.
16 PASSWORDS
Two separate passwords may be set to control access to the Calibration section and to the menu and
other keys. To access the passwords setup screen, select Passwords from the menu. The display
appears as follows:
16.1 Calibration Password
Select Calibration from the sub-menu. The display appears as follows:
To set the password, select Enabled, then Set Password. Use the UP and DOWN keys to increment and
decrement the value, from 0 to 9999. When the desired value has been selected, press ENTER, then
ESC to exit the sub-menu.
16.2 MENU Key Password
If enabled, every time the MENU key is selected, a password must be provided. Select Menu Key from
the sub-menu. Follow the same procedure as described above.
PASSWORDS
Calibration
Menu Key
Units Key
Mode Key
Zero Key
Data Key
CALIBRATION
PASSWORD
*
Disabled
Enabled
Set Password
(0000 – 9999)
CALIBRATION
TENSION
Load too close
to previous.
Please try again.
