Model 7i Digital Force / Torque Indicator User’s Guide
39
18 SPECIFICATIONS
18.1 General
Accuracy: ±0.1% of full scale + sensor
Sampling rate: 14,000 Hz
Power: AC or rechargeable battery. Low battery indicator appears when battery level is low, and
indicator powers off automatically when power reaches critical stage.
Battery life:
Backlight on: up to 7 hours of continuous use
Backlight off: up to 12 hours of continuous use
Measurement units:
lbF, ozF, gF, kgF, N, kN, mN, lbFft, lbFin, ozFin, kgFm, kgFmm, gFcm, Nm, Ncm, Nmm
(depending on sensor)
Outputs:
USB / RS-232: Fully configurable up to 115,200 baud. Includes GCL2 (Gauge Control
Language 2) for full computer control.
Mitutoyo (Digimatic): Serial BCD suitable for all Mitutoyo SPC-compatible devices.
Analog: ±1 VCD, ±2% of full scale at capacity.
General purpose: Three open drain outputs, one input.
Set points: Three open drain lines.
Weight: 0.7 lb [0.3 kg]
Included accessories:
Carrying case, AC adapter, battery, USB cable, resource CD (USB driver, MESUR
TM
Lite
software, MESUR
TM
gauge DEMO software, and user’s guide), NIST-traceable certificate
of calibration
Environmental
requirements:
40 - 100°F, max. 96% humidity, non-condensating
Warranty: 3 years (see individual statement for further details)
18.2 Factory Default Settings
Parameter Setting
Set points
Upper Disabled (defaults to 80% of full scale, C/CW, when enabled)
Lower Disabled (defaults to 40% of full scale, C/CW, when enabled)
Filters
Current
16
Displayed 2048
Average mode Disabled
Initial Delay 0
Trigger Load 10% of full scale
Averaging Time (sec.) 5.0
Auto Output Settings All disabled
Auto Zero Delay 5 sec.
External Trigger Disabled
Auto Output Settings All disabled
Auto Zero Delay 5 sec.
DATA Key Functions
RS-232/USB Output Enabled
Mitutoyo Output Disabled
Memory Storage Enabled
Auto Zero Disabled
Auto Zero Delay 5 sec.
Serial/USB
RS-232 Output Selected
Enabled
USB Output Selected Disabled
Baud Rate 9,600
