CF10 19 6/24/08 Rev. H
used (refer to the Settings menu item).
Seconds Sensor 1 Sensor 2 Sensor 3
0 7.894737 5.263158 5.263158
0.125 44.73684 15.78947 5.263158
0.25 97.36842 92.10526 15.78947
0.375 134.2105 171.0526 73.68421
4.4.3 Edit Menu
Edit Menu (same when focus is on either a Real-time or Movie Window):
Copy:
saves the current Real-time or Movie frame to the MS Windows clipboard. This data is saved in the
clipboard as a graphic (bitmap) image of the current window. Once copied to the clipboard, this data can be pasted
into other Windows applications by selecting Edit -> Paste.
The following image shows how the copy command can be used to import an image of the current window into MS
Excel:
4.4.4 View Menu
View Menu when focus is on a Real-time Window: View Menu when focus is on a Movie Window:
Strip Chart:
is the default display mode, where force value is displayed on the Y-Axis and elapsed time is
displayed on the X-Axis.
