167-073M Table of Contents Index 2012-10-17
12 ADC2220 Table of Contents Index Great Plains Manufacturing, Inc.
Introduction
Great Plains welcomes you to its growing family of new
product owners. Your Air Drill Cart has been designed
with care and built by skilled workers using quality
materials. Proper setup, maintenance, and safe
operating practices will help you get years of satisfactory
use from the machine.
Air Cart Document Family
167-073M Owner’s Manual (this document)
including Seed Rate charts
167-073P Parts Manual
Description of Unit
The ADC2220 is a pull-type implement for volumetric
seeding. A hydraulic fan creates an airflow to supply
seed and dry treatments to a compatible trailing Great
Plains drill.
The ADC2220 Air Drill Cart is compatible with the
following Great Plains air drills:
Note: If the air cart and drill were not purchased on the
same original factory order, one or both may not
include compatible components. The implements
above may be configured for use with other air
carts. Check with your dealer before hitching.
Intended Usage
Use the air cart and drill to seed production-agriculture
crops only. Do not modify the air cart for use with
attachments other than Great Plains options and
accessories specified for use with the air cart.
Using This Manual
This manual will familiarize you with safety, assembly,
operation, adjustments, troubleshooting, and
maintenance. Read this manual and follow the
recommendations to help ensure safe and efficient
operation.
The information in this manual is current at printing.
Some parts may change to assure top performance.
Definitions
The following terms are used throughout this manual.
Right-hand and left-hand as used in
this manual are determined by facing
the direction the machine will travel
while in use unless otherwise stated.
An orientation rose in some line art
illustrations shows the directions of:
Up, Back, Left, Down, Front, Right.
A crucial point of information related to the preceding topic.
For safe and correct operation, read and follow the directions
provided before continuing.
Note: Useful information related to the preceding topic.
ADI334 34-foot Air Drill Implement
ADI345 45-foot Air Drill Implement
CTA4000 40-foot Conventional Tillage Air Drill
CTA4000HD Heavy Duty Tillage Air Drill
NTA3010 30-foot No-Till Air Drill
NTA3510 35-foot No-Till Air Drill
Figure 1
Air Cart and Drill
16179
Figure 2
Left/Right Notation
16263
L
R
U
D
F
B
L
R
