UMC Rigid Tine Row Cleaners
Optional single-arm unit-mount rigid tine row cleaners
are available as an Option with the planter, or as parts for
later installation. One kit includes all 8 row cleaners
(4 left, 4 right).
This kit requires that unit-mount disk coulters (below)
also be installed, as the arms of the cleaners attach to
the coulter. If ordering as a Part, also order or download
the manual.
For operation, see “Row Cleaner Adjustments” on
page 47.
UM Disk Coulters
Optional unit-mount disk coulters are available with
38 cm (15 inch) fluted or turbo blades are available as an
Option with the planter, or for later installation as a Part.
If ordered as Parts, order 1 per row (8 total):
For operation, see “Coulter Adjustments” on page 48.
Coulter Blades
Replacement and alternate UM coulter blades include
(order one per coulter):
Description Option Part Number
UMC Rigid Row Cleaners (90) 207-205A
Manual: Install/Operate/Parts n/a 204-085M-A
Figure 123
Rigid Tine Row Cleaner
25479
Description Option Part Number
UMC, 15 inch Fluted Blade (86) 204-661A
UMC, 15 inch Turbo Blade (87) 204-662A
Figure 124
Unit-Mount Coulter
25480
Description Part Number
Turbo, 38 cm (15 inch) (20 flutes) 820-327C
Fluted, 38 cm (15 inch) (50 flutes) 820-331C
Figure 125
Turbo & Fluted Coulter Blades
25299
