Great Plains Manufacturing, Inc. Table of Contents Index Options 89
2014-07-23 Table of Contents Index 401-479M
Frame-Mounted Row Options
Frame-Mounted Row Cleaners
Terra-Tine™ row cleaners are available in two
frame-mounted versions, and also as unit-mount
(page 91). They may be ordered with the planter, or
installed later. For operation, see “Terra-Tine™ Row
Cleaners” on page 42.
Stand-Alone Terra-Tine™s
This kit includes the frame clamps and shanks. Each part
number includes a left and a right assembly. If ordering
the part number, order 4 per planter.
Vantage I Terra-Tine™s
This kit relies on the shank components of the Zone
Coulter or Vantage I. Each part number includes a left
and a right assembly. If ordering the part number, order 4
per planter.
Zone Coulters
This is a 43 cm (17 inch) disk coulter. Mounting may be
adjusted for zone or in-row tillage. If liquid fertilizer
application is also required, see “Vantage I Fertilizer
Coulter” on page 90.
Zone coulters may be ordered as Options with the
planter, or installed later. For operation, see “Zone
Coulters” on page 43. This kit includes one blade set,
the frame clamps and shanks. Each part number
includes a left and a right coulter assembly. If ordering
the part number, order 4 per planter. For replacement
blades, order 1 per row.
Description Option Part Number
Terra-Tine™ 5
×7 Mount
(91) 407-051A
Description Option Part Number
Terra-Tine™ Vantage I (92) 407-052A
Description Option Part Number
Zone Coulter Wavy Blade (81) 407-040A
Zone Coulter Turbo Blade (82) 407-041A
Wavy Blade, 17 inch n/a 820-082C
Turbo Blade, 17 inch n/a 820-156C
Figure 117
Frame-Mounted Terra-Tine™
22513
Figure 118
Frame-Mounted Zone Coulter
25392
