Great Plains Manufacturing, Inc. Table of Contents Index 97
Appendix A - Reference Information
Specifications and Capacities
Tire Inflation Chart
PD8070
HP Requirements 75-104 kW (100-140 hp) estimated minimum
Hydraulic Circuits 2 (closed/open center), 15 Pa, 40 liters/min (2250 psi, 10.63 gallons/min.)
Hitch Pull-type
Transport Width 6.4 m (21 feet)
Working Width 4.9 m (16 feet)
Transport Length 4.6 m (15 feet)
Transport Clearance 38 cm (15 inches)
Transport Height 1.95 m (6 feet 5 inches)
Weight (Approx.) 3114 kg (6875 pounds)
Frame Construction 17.8 ×17.8 cm, 7.9 mm wall (7x7 inch, 5 ⁄
16
inch wall) main tool bar
Meter Drive Ground Drive (2-wheel w/ratchet differentials)
Transmission End Mounted
Row Spacing (inches) 70 cm (27.6 inches)
Seed Hopper Capacity 564 liters {70.5 × 8} (16 bushels {2 bushels per hopper × 8})
Fertilizer Hopper Capacity
250 kg (550 pounds) per hopper
Tire Sizes
Transport: four 7.00-15LT
Contact Drive: two 13-6.50
×6
Number of Openers 8
Opener Down Force
38.5-70.2 kg std., 70-111 kg optional
(85-155 pounds std., 155-245 pounds optional)
Opener Travel 12.7 cm up, 12.7 cm down (5 inches up/down, 10 inches total)
Opener Depth Range
0 to 10.2 cm, 6.5 mm increments (0 to 4 inches,
1 ⁄
4
inch increments)
Tire Size Pressure Tire Warranty Information
Transport 7.00-15LT
414kPa
(60 psi) All tires are warranted by the original manufacturer of
the tire. Tire warranty information is found in the
brochures included with your Operator’s and Parts
Manuals or online at the manufacturer’s web sites
listed below. For assistance or information, contact
your nearest Authorized Farm Tire Retailer.
Manufacturer Web Site
Titan www.titan-intl.com
Goodyear Now: www.titan-intl.com
Firestone www.firestoneag.com
Contact 13-6.50
×6
276 kPa
(40 psi)
