may lead to slight variations in the test results. To eliminate this error the tubes shoulbe
placed in the chamber with the same orientation each time. The orientation of the
tubes in the chamber is controlled by use of a tube positioning ring. For improved
accuracy and precision, especially at low concentrations, the tubes should always be
used with a positioning ring. (See page 22)
PC LINK
The TC-3000 may be interfaced with any Windows-based computer by using the
LaMotte SMARTLink 2 Program and Interface Cable (Code 1912-3 with 3.5 inch disk
or Code 1912-CD with compact disk). The program will store test information and
results in a database. The meter may also be interfaced with an RS232 serial printer,
using an interface cable (Code 1772) and setting the printer configuration to the
Output as described below.
OUTPUT
RS232 compatible, asynchronous serial, 9600 baud, no parity, 8 data bits, 1 stop bit.
COMPUTER CONNECTION
RS232 interface connection, 8 pin mini-DIN/9 pin F D-submin. (Order Interface
Cable Code 1772).
BATTERY OPERATION
The TC-3000 may be operated on battery power or using an AC adapter. If using the
meter as a bench top unit, use the AC adapter if possible. If using the meter only on
battery power, always keep a spare battery on hand.
REPLACING THE BATTERY
The TC-3000 uses a standard 9-volt alkaline battery that is available worldwide. The
battery compartment is located on the bottom of the case.
To replace the battery:
1. Open the battery compartment lid.
2. Remove the battery and disconnect the battery from the polarized plug.
3. Carefully connect the new battery to the polarized plug and insert it into the
compartment.
4. Close the battery compartment lid.
MAINTENANCE
CLEANING
Clean meter with a damp, lint-free cloth.
DO NOT ALLOW WATER TO ENTER THE METER CHAMBER OR ANY OTHER PARTS
OF THE METER.
Clean meter chamber and lenses over LEDs with a lint-free cloth slightly dampened
with alcohol.
66 PC LINK • BATTERY OPERATION • MAINTENANCE
