APPENDIX
A-6
Manual 0-2653
APPENDIX 5: QUICK REFERENCE TO INTERCONNECTING
CABLES AND HOSES
Cable/Hose Diameter
Cable/Hose Diameter
Cable
Description
Catalog #
Inches
mm
Cable
Description
Catalog #
Inches
mm
A
Power Supply CNC Cable
I
Work Cable
25 ft (7.6 m)
8-3380
3/8
9.5
25 ft (7.6 m)
9-6892
3/4
19
50 ft (15.2 m)
8-3381
3/8
9.5
35 ft (10.7 m)
9-6926
3/4
19
75 ft (22.9 m)
8-3382
3/8
9.5
50 ft (15.2 m)
9-6927
3/4
19
100 ft (30.5 m)
8-3383
3/8
9.5
75 ft (22.9 m)
9-6928
3/4
19
B
Remote Control Cable
100 ft (30.5 m)
9-6896
3/4
19
25 ft (7.6 m)
9-5961
1/2
13
115 ft (35.1 m)
9-6856
3/4
19
50 ft (15.2 m)
9-5962
1/2
13
125 ft (38.1 m)
9-6929
3/4
19
75 ft (22.9 m)
9-5963
1/2
13
J
Parallel Cable - 8 ft (2.4 m)
9-6800
1/2
13
100 ft (30.5 m)
9-5964
1/2
13
Parallel Cable - 30 ft (9.1 m)
9-6997
1/2
13
C
Gas Control Cable
K
CNC Cable
10 ft (3.0 m)
9-6934
1/2
13
5 ft (1.5 m)
9-4483
5/8
16
15 ft (4.6 m)
9-6935
1/2
13
10 ft (3.0 m)
9-4484
5/8
16
20 ft (6.1 m)
9-6936
1/2
13
15 ft (4.6 m)
9-4485
5/8
16
25 ft (7.6 m)
9-6937
1/2
13
20 ft (6.1 m)
9-4486
5/8
16
30 ft (9.1 m)
9-6938
1/2
13
25 ft (7.6 m)
9-4486-25
5/8
16
35 ft (10.7 m)
9-6939
1/2
13
30 ft (9.1 m)
9-4486-30
5/8
16
40 ft (12.2 m)
9-6940
1/2
13
50 ft (15.2 m)
9-4486-50
5/8
16
50 ft (15.2 m)
9-6941
1/2
13
L
Pre-Flow Gas Hose #4
75 ft (22.9 m)
9-6942
1/2
13
10 ft (3.0 m)
9-6956
1/2
13
100 ft (30.5 m)
9-6943
1/2
13
15 ft (4.6 m)
9-6957
1/2
13
125 ft (38.1 m)
9-6944
1/2
13
20 ft (6.1 m)
9-6958
1/2
13
D
Arc Starter Control Cable
25 ft (7.6 m)
9-6959
1/2
13
10 ft (3.0 m)
9-6945
1/4
6
30 ft (9.1 m)
9-6960
1/2
13
15 ft (4.6 m)
9-6946
1/4
6
35 ft (10.7 m)
9-6961
1/2
13
20 ft (6.1 m)
9-6947
1/4
6
40 ft (12.2 m)
9-6962
1/2
13
25 ft (7.6 m)
9-6948
1/4
6
50 ft (15.2 m)
9-6963
1/2
13
30 ft (9.1 m)
9-6949
1/4
6
75 ft (22.9 m)
9-6964
1/2
13
35 ft (10.7 m)
9-6950
1/4
6
100 ft (30.5 m)
9-6965
1/2
13
40 ft (12.2 m)
9-6951
1/4
6
125 ft (38.1 m)
9-6966
1/2
13
50 ft (15.2 m)
9-6952
1/4
6
M
Secondary RAS & Plasma RAS Hoses
75 ft (22.9 m)
9-6953
1/4
6
5 ft (1.5 m)
9-6967
1/2
13
100 ft (30.5 m)
9-6954
1/4
6
10 ft (3.0 m)
9-6968
1/2
13
125 ft (38.1 m)
9-6955
1/4
6
15 ft (4.6 m)
9-6969
1/2
13
E
Positive Pilot Supply Cable
20 ft (6.1 m)
9-6970
1/2
13
35 ft (10.7 m)
9-6906
1/4
6
25 ft (7.6 m)
9-6971
1/2
13
50 ft (15.2 m)
9-6907
1/4
6
30 ft (9.1 m)
9-6972
1/2
13
75 ft (22.9 m)
9-6908
1/4
6
35 ft (10.7 m)
9-6973
1/2
13
100 ft (30.5 m)
9-6886
1/4
6
40 ft (12.2 m)
9-6974
1/2
13
115 ft (35.1 m)
9-6857
1/4
6
50 ft (15.2 m)
9-6975
1/2
13
125 ft (38.1 m)
9-6909
1/4
6
N
Pre-Flow RAS Hose
F
Plasma or Secondary Gas Hose #4
5 ft (1.5 m)
9-6976
1/2
13
10 ft (3.0 m)
9-6910
1/2
13
10 ft (3.0 m)
9-6977
1/2
13
15 ft (4.6 m)
9-6911
1/2
13
15 ft (4.6 m)
9-6978
1/2
13
20 ft (6.1 m)
9-6912
1/2
13
20 ft (6.1 m)
9-6979
1/2
13
25 ft (7.6 m)
9-6913
1/2
13
25 ft (7.6 m)
9-6980
1/2
13
30 ft (9.1 m)
9-6914
1/2
13
30 ft (9.1 m)
9-6981
1/2
13
35 ft (10.7 m)
9-6915
1/2
13
35 ft (10.7 m)
9-6982
1/2
13
40 ft (12.2 m)
9-6916
1/2
13
40 ft (12.2 m)
9-6983
1/2
13
50 ft (15.2 m)
9-6917
1/2
13
50 ft (15.2 m)
9-6984
1/2
13
75 ft (22.9 m)
9-6918
1/2
13
100 ft (30.5 m)
9-6919
1/2
13
125 ft (38.1 m)
9-6920
1/2
13
G
Coolant Hose #8
35 ft (10.7 m)
9-6921
7/8
22
50 ft (15.2 m)
9-6922
7/8
22
75 ft (22.9 m)
9-6923
7/8
22
100 ft (30.5 m)
9-6924
7/8
22
115 ft (35.1 m)
9-6858
7/8
22
125 ft (38.1 m)
9-6925
7/8
22
H
Torch (-) Cable
25 ft (7.6 m)
9-6892
3/4
19
35 ft (10.7 m)
9-6926
3/4
19
50 ft (15.2 m)
9-6927
3/4
19
75 ft (22.9 m)
9-6928
3/4
19
100 ft (30.5 m)
9-6896
3/4
19
115 ft (35.1 m)
9-6856
3/4
19
125 ft (38.1 m)
9-6929
3/4
19
