Tweco 100 Auto-Cut User Manual
Page 16

Manual Nro. 0-4764
2-4
ESPECIFICACIONES
Soporte de la
cubierta de
los terminales
Tanque de
refrigerante
Filtro de refrigerante
Conexiones de
refrigerante
Terminales de la
alimentación eléctrica
Terminal positivo
del piloto
Panel de interruptores
Cubierta de
los terminales
Lámpara de señalización
entrada CA
Terminales de puesta
a tierra
Conector del control
de gas
RETORNO
SUMINISTRO
Art # A-04823_spa
Conexión al CNC
Conector del
iniciador de arco
Terminal de masa
Terminal negativo
de la antorcha
Acceso de las conexiones de la antorcha
Accesos de gas
Conector del control de gas
Conector del
iniciador de arco
Soporte en “C”
para cables
Elementos del panel posterior de la fuente de alimentación
