Adjust menus – tekmar 262 Boiler Control Installation User Manual

Page 21

background image

21 of 36

Copyright © D 262 -

12/08

Section

262 Adjust Menu (1 of 4)

The desired room air temperature during an
Occupied period.
Note: There is only a 13

°F adjustment in the LTD

access level.
DIP switch =

Characterized Heating Curve

No RTU connected

MODE = —1—

35 to 100˚F
(2 to 38˚C)

Default = 70

°F (21°C)

35 to 100˚F
(2 to 38˚C)

Default = 65

°F (18°C)

The desired room air temperature during an
UnOccupied period.
DIP switch =

Characterized Heating Curve

DIP switch =

Setback

No RTU connected
MODE = —1—

NONE,
INDR (Indoor)
Zoin, SLAB

Default = NONE

The device that is to be connected to the 10K
input terminal.

DIP switch =

Characterized Heating Curve

No RTU connected
MODE = —1—

OFF, 35 to 120˚F
(OFF, 2 to 49˚C)

Default = 70

°F (21°C)

40 to 150˚F
(4 to 66˚C)

Default = 90

°F (32°C)

The minimum temperature at the slab sensor

DIP switch =

Characterized Heating Curve

No RTU connected
10K = SLAB

Boil MIN = OFF

MODE = —1—

OFF, 0:20 to 8:00 hr

Default = OFF

The maximum temperature at the slab sensor.

DIP switch =

Characterized Heating Curve

No RTU connected
10K = SLAB

Boil MIN = OFF

MODE = —1—

The amount of morning boost.
DIP switch =

Characterized Heating Curve

DIP switch =

Setback

No RTU connected
10K

≠ Zoin

MODE = —1—

The amount the boiler supply water temperature
will be reduced when the control is in the
UnOccupied mode.

DIP switch =

Reset Ratio

DIP switch =

Setback

M O D E = — 1 —

0 to 50˚F
(0 to 28˚C)

Default = 15

°F (8°C)

The type of terminal units that are being used in
the heating system.

DIP switch =

Characterized Heating Curve

MODE = —1—

HRF1 (Heavy), HRF2
(Light), (Fan-) COIL,
CONV (ector), RAD
(iator), BASE (board)

Default = CONV

The design indoor air temperature used in the
heat loss calculations for the heating system.

DIP switch =

Characterized Heating Curve

MODE = —1—

35 to 100˚F
(2 to 38˚C)

Default = 70

°F (21°C)

Actual

Setting

Sets the operating Mode for the control.

MODE —1— = (

Heating, DHW, and Setpoint)

MODE —2— = (

Dedicated DHW)

—1— or —2—

Default = MODE —1—

Occ

UnOcc

LT

D

USER INST ADV

Range

Access
Level

Description

Item Field

A

B1

B1

B2

B2

B2

B1

B1

B1

B1
