33 E-flite Hawker Sea Fury 400 ARF Assembly Manual
 12. Thread the clevis back on the pushrod wire. Connect
the clevis to the rudder control horn.
 13. With the radio system on, adjust the position of the
clevis so the rudder is parallel to the fin.
Final Assembly
Required Parts
Rocket (6) 3mm x 45mm machine screw (2)
Battery stop Canopy
Required Tools and Adhesives
Phillips screwdriver: #1
 1. Connect the aileron servo extensions to the aileron
harness. The retract leads will pass into the fuselage and
connect to the receiver with a Y-harness or plug directly
into the receiver if using separate channels.
