25 E-flite Hawker Sea Fury 400 ARF Assembly Manual
 4. Slide the tail wheel onto the tail gear wire.
 5. Secure the wheel using the wheel axle cap and
foam-safe CA. Use care not to get CA between the
tail gear wire and wheel, which will prevent the
wheel from rolling.
Optional Operable Rudder
Required Parts
Control horn Control horn backplate
2mm x 10mm sheet metal screw (2)
Operational tail gear wire Tail wheel
Wheel spacer Wheel axle cap
Required Tools and Adhesives
Hobby knife Foam-safe CA
Drill bit: 1/8-inch (3mm) Pin drill
Felt-tipped pen Sandpaper
Note: Although the optional rudder can be installed after
the stabilizer, it is much easier to do so before installing
the stabilizer. The photos show the stabilizer installed
for reference, even though the actual installation will be
covered later in the manual.
 1. Use a hobby knife to cut the rudder from the fin. Cut
as close to the fin as possible for the best results.
